ITEM |
UNIT |
MODEL AND TECHNICAL PARAMETER |
50T |
100T |
150T |
200T |
Storage Capcity |
T |
50 |
100 |
150 |
200 |
Discharging Height |
MM |
1960¡¢4200 |
1960¡¢4200 |
1960¡¢4200 |
1960¡¢4200 |
Diameter of Silo |
MM |
¦µ2800 |
¦µ2800 |
¦µ3200 |
¦µ4500 |
Height of Silo |
MM |
9790 |
14300 |
19210 |
14710 |
Diameter of Feed Inlet ¦µ |
MM |
102 |
102 |
102 |
102 |
Assembly Mode
of Cement Silo |
|
Splice Type with bolts,
Overall Welding |
Splice Type with bolts,
Overall Welding |
Splice Type with bolts,
Overall Welding |
Splice Type with bolts,
Overall Welding |
Arch Breaking Form |
|
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Form of Cleaner |
|
Filtration of Filter |
Filtration of Filter |
Filtration of Filter |
Filtration of Filter |
Level Controller |
|
Resistance and
suspension Controller |
Resistance and
suspension Controller |
Resistance and
suspension Controller |
Resistance and
suspension Controller |
Total Weight |
T |
4 |
7 |
10.5 |
12.2 |
Remarks:£º
Our Company reserves the right to update and improve our products without any notice.Buyers should refer to actual parameters offered by our dealers. |
